Specification Table
| Machine range | Specification model number | unit | Ne450 | Nc600 | Nc800 | Nc1100 | Nc1300 |
| Processing length (maximum) | mm | 450 | 610 | 810 | 110 | 130 | |
| Processing length (minimum) | mm | 20 | 30 | 30 | 100 | 100 | |
| Processing width (maximum) | mm | 450 | 610 | 810 | 1100 | 1300 | |
| Processing width (minimum) | mm | 20 | 30 | 30 | 100 | 100 | |
| Workbench size | mm | 400X400 | 450x450 | 450x450 | 800x800 | 800x800 | |
| Double sided milling head spindle parameters | Processing height | mm | 200 | 250 | 250 | 250/300 | 250/300 |
| Milling head model | 2个 | ZJ-190 | ZJ-200 | ZJ-210 | ZJ-230 | TY-240 | |
| Cutting form | Heavy duty precision spindle | Heavy duty precision spindle | Heavy duty precision spindle | Heavy duty precision spindle | Heavy duty precision spindle | ||
| Spindle motor power | KW | 7.5 | 11 | 15 | 15 | 15 | |
| Spindle transmission mode | Belt inline/gear type | Belt inline/gear type | Belt inline/gear type | Belt inline/gear type | Belt inline/gear type | Belt inline/gear type | |
| Spindle travel (unilateral) | mm | 250 | 330 | 420 | 550 | 550 | |
| spindle taper | NT50# (7 : 24) | NT5Q# (7 : 24) | NT50#(7:24) | NT50#(7:24) | NT50#(7:24) | ||
| Number of spindle segments | paragraph | stepless speed change | stepless speed change | stepless speed change | stepless speed change | stepless speed change | |
| Spindle speed scale | min | 150-550 | 150-550 | 150-550 | 150-550 | 150-550 | |
| Outer diameter of quasi iron knife | mm | C250 | C250 | C250 | <250 | C250 | |
| Machine parameter | Maximum load capacity of machine tool | T | 515KG | 1250KG | 1560KG | 1820KG | 2120KG |
| Machine weight (approximately) | T | 7.25 | 8.5 | 10.85 | 12.55 | 13.55 | |
| Dimensions and Length | mm | 2900 | 4000 | 4000 | 4200 | 6000 | |
| Dimensions and Width | mm | 3500 | 3600 | 3800 | 5800 | 4500 | |
| Dimensions and Height | mm | 2100 | 2200 | 2100 | 2300 | 2300 |
Note: Due to continuous mechanical improvement and data updates, all data changes are subject to actual conditions
