Standard attachments:
Toolbox and Tools
Electromagnetic suction cup
Simple Program Control System
| Specification Table | |||||
| Model | unit | TP1580A | TP2015A | TP2515A | notes |
| Machining(mm) | |||||
| Maximum milling length | mm | 1500 | 2000 | 2500 | |
| Maximum milling width | mm | 1100 | 1500 | 1500 | |
| Distance between two columns | mm | 1150 | 1500 | 1550 | |
| Maximum passing height | mm | 500 | 500 | 500 | |
| Table size | mm | 1500X800 | 2000X1200 | 2500X1200 | |
| Speed parameter(mm/min) | |||||
| Table speed | m/m | 100-5000 | 100-5000 | 100-5000 | |
| Milling head left and right speed | k/m | 20-3000 | 20-3000 | 20-3000 | |
| Milling head power | HP | 12.5 | 15 | 15 | |
| power parameters(HP) | |||||
| Workbench motor | KW | 3 | 3 | 5.5 | Variable frequency/servo |
| Milling head left and right motors | KW | 1.5 | 1.5 | 1.5 | Variable frequency/servo |
| Milling head upper and lower motors | KW | 1.5 | 1.5 | 2 | Variable frequency/servo |
| OTHERS | |||||
| Machine tool load-bearing capacity | KG | 2000 | 3000 | 4000 | |
| Mechanical weight (approximately) | KG | 9000 | 12000 | 18000 | |
| Dimensions (length X width X height) | 5200X2300X2400 | 6200X2900X2700 | 7600X3700X3800 | ||
Note: Due to continuous mechanical improvement and data updates, all data changes are subject to actual conditions
